Find the right product for your applications.
Increase positioning accuracy while reducing development time
Save development time by using prebuilt GNSS receiver boards that feature Vanguard Technology™ with Universal Tracking Channels™ for reliable "all in view" tracking. These low-power consumption boards provide centimeter-level accuracy and sub-degree heading orientation for positioning applications.
Compare products
B111A
Signals tracked
GPS: L1, L2, L2C
GLONASS: L1, L2, L2C
BeiDou: B1, B2
Galileo: E1
SBAS: L1
QZSS: L1, L2C
Positioning
RTK
PPP
DGNSS
Stand-alone
Heading
HD2, Azimuth filter
Update rate
Up to 100 Hz
Hot/cold start
< 15 sec / < 44 sec typical
Reacquisition
< 1 sec
Power consumption
3.4 VDC to 4.5 VDC / 1.3 W typical
Operating temperature
-40°C to +85°C
Vibration
4g Sine Vibe (SAEJ1211); 7.7g Random Vibe (MIL-STD 810F)
Dimensions
40 mm x 55 mm x 10 mm
Weight
< 20 g
B125
Signals tracked
GPS: L1, L2, L2C, L5
GLONASS: L1, L2, L3
BeiDou: B1, B2
Galileo: E1, E5a, E5b, E5AltBOC
SBAS: L1
QZSS: L1, L2, L1C, L1-SAIF, L2C,
L5 L-band
Positioning
RTK
PPP
DGNSS
Stand-alone
Heading
HD2, Azimuth filter
Update rate
Up to 100 Hz
Hot/cold start
< 15 sec / < 44 sec typical
Reacquisition
< 1 sec
Power consumption
3.4 VDC to 5.5 VDC / 2.0 W typical
Operating temperature
-40°C to +85°C
Vibration
4g Sine Vibe (SAEJ1211); 7.7g Random Vibe (MIL-STD 810F)
Dimensions
55 mm x 40 mm x 10 mm
Weight
< 20 g
B210
Signals tracked
GPS: L1, L2, L2C, L5
GLONASS: L1, L2, L3
BeiDou: B1, B2
Galileo: E1, E5a, E5b, E5AltBOC
SBAS: L1
QZSS: L1, L2, L1C, L1-SAIF, L2C, L5
L-band
Positioning
RTK
PPP
DGNSS
Stand-alone
Heading
VHD
Update rate
Up to 100 Hz
Hot/cold start
< 15 sec / < 44 sec typical
Reacquisition
< 1 sec
Power consumption
3.3 VDC to 4.5 VDC / 2.5 W typical
Operating temperature
-40°C to +85°C
Vibration
4g Sine Vibe (SAEJ1211); 7.7g Random Vibe (MIL-STD 810F)
Dimensions
60 mm x 100 mm x 12 mm
Weight
